Attributes
Glass Coating MachineMachine Type
Pneumatic, ElectricProduction Capacity
380 VVoltage
1.65Power(w)
1 to 10mmGlass Thickness
Guangdong, ChinaPlace of Origin
Weight:100 kg
Warranty:1 Year
Key Selling Points:Easy To Operate
Core Components:Motor, Rubber roller, Film frame iron pipe, Pneumatic, components, Control System
Color:White
Material:Steel
Brand Name:JUNDE
Dimension(L*W*H):1200x1200x1050mm
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Input Power:220V/50HZ
Working Air Pressure:0.4~0.8MPa
Total Power:1.65kW (2kW for 1.1m Model, 2.5kW for 1.3m Model)
Heating Wire Power:1.1kw
Spindle Power:0.55kw
Rubber Roller Preheating Time:10-15 Minutes
Laminating Width:10 to 850mm (Customizable for 1.1m and 1.3m Laminating Machines)
Laminating Thickness:1 to 10mm
Large Roller Size:100
Number of Rollers:7 Pcs of 40 (8 Pcs for 1.1m and 1.3m Models)
Pneumatic Components:2 Pcs of 63*25 Air Cylinders (Adjustable Cylinders Optional)
Film Rack Iron Pipe:1 Pc of 32 (2 Pcs of 32 for Automatic Material Collection)
Laminating Speed:Approx. 6m/min
Overall Dimensions:1200*1200*1050mm
