Attributes
Horizontaltype
CNCcnc or not
220V/380Vvoltage
3number of axes
11/15spindle motor power(kw)
1320*1020table size (mm)
Automatic Grade:Automatic
no. of spindles:Single
key selling points:Competitive Price
core components:Motor
warranty:1 Year
machinery test report:Provided
video outgoing-inspection:Provided
table travel (x) (mm):1250
table travel (y) (mm):900
table travel (z) (mm):1350
range of spindle speed(r.p.m):1100
place of origin:Henan, China
weight (t):15
max. table load(kg):2500
travel (w-axis) (mm):550
positioning accuracy (x axis) mm:0.02
positioning accuracy (y axis) mm:0.02
positioning accuracy (z axis) mm:0.02
production capacity:50-100 Sets/month
brand name:Wadley
dimension(l*w*h):5380*3000*3050
Product name:High Precision Cnc Boring Machine
Spindle diameter:110mm
Max. boring diameter:240mm
Max.drilling diameter:50mm
Taper of spindle:BT50
Feeding range(mm/min):0.2-330
Feed speed range(mm/min):0.5-1000
Facing head speed range:4-130rpm
Warranty of core components:1 Year
Condition:New
