TASI TA811C Digital Clamp Meter 5999 Counts AC 600A Auto Range Measures Capacitance DC Current Resistance Frequency Diode CAT
Store rating:5.0
(129 reviews)
Attributes
CAT IV 600VInstrument Safety Rating
AC Voltage, AC CURRENT, Capacitance, DC Current, DC Voltage, Frequency, Resistance, TEMPERATUREParameters Measured
0-600 AMeasuring Current Range
0.1-600 VMeasuring Voltage Range
±(0.5% + 3)Accuracy Class
Φ26 mmClamp Opening Size
Max. Ac Current:600 A
Max. DC Current:600 A
Max. Ac Voltage:600 V
Max. DC Voltage:600 V
Display Type:Digital Only
Frequency Range:10Hz~10MHz+(1.0%+3)
Measuring Resistance Range:0-60 mΩ
Measuring Capacitance Range:1nF~100000µF+(4.0%±5)
Operating Temperature:0 °C ~ 45 °C
Measuring Inductance Range:No
Place of Origin:Jiangsu, China
Model Number:TA811C
Brand Name:TASI
Dimensions:194*73*31mm
Weight:177g
Product name:Clamp Meter
DC voltage:0.1mV~600V±(0.5%+5)
AC voltage:0.001V~600V±(0.8%+5)
DC current:0.01A~600A±(2.5%+5)
AC current:0.01A~600A±(2.5%+5)
Resistance:0.1Ω~60MΩ±(1.0%+5)
Capacitance:1nF~100,000μF±(54.0%+5)
Frequency:10Hz~10MHz±(1.0%+3)
Temperature:-20~1000°C±(1.0%+2)
Delivery contents:Meter, box, cloth bag, manual, test leads x1 pair, thermocouple probe
Key attributes
Instrument Safety Rating
CAT IV 600V
Parameters Measured
AC Voltage, AC CURRENT, Capacitance, DC Current, DC Voltage, Frequency, Resistance, TEMPERATURE
Measuring Current Range
0-600 A
Measuring Voltage Range
0.1-600 V
Accuracy Class
±(0.5% + 3)
Clamp Opening Size
Φ26 mm
Max. Ac Current
600 A
Max. DC Current
600 A
Max. Ac Voltage
600 V
Max. DC Voltage
600 V
Display Type
Digital Only
Frequency Range
10Hz~10MHz+(1.0%+3)
Measuring Resistance Range
0-60 mΩ
Measuring Capacitance Range
1nF~100000µF+(4.0%±5)
Operating Temperature
0 °C ~ 45 °C
Measuring Inductance Range
No
Place of Origin
Jiangsu, China
Model Number
TA811C
Brand Name
TASI
Dimensions
194*73*31mm
Weight
177g
Product name
Clamp Meter
DC voltage
0.1mV~600V±(0.5%+5)
AC voltage
0.001V~600V±(0.8%+5)
DC current
0.01A~600A±(2.5%+5)
AC current
0.01A~600A±(2.5%+5)
Resistance
0.1Ω~60MΩ±(1.0%+5)
Capacitance
1nF~100,000μF±(54.0%+5)
Frequency
10Hz~10MHz±(1.0%+3)
Temperature
-20~1000°C±(1.0%+2)
Delivery contents
Meter, box, cloth bag, manual, test leads x1 pair, thermocouple probe
Packaging and delivery
Selling Units
Single item
Single package size
25X13.5X7 cm
Single gross weight
0.530 kg
Lead time
