Portable Mini Concrete Pump Dual Option Mobile Concrete Pump With Remote Control Concrete Conveying Pump

No reviews yet
$1,400
1-9 sets
$1,120
≥10 sets

Model Number

HBTS-20 Concrete Pump
HBTS-10 Concrete Pump
HBTS-30 Concrete Pump
HBTS-40 Concrete Pump
HBTS-50 Concrete Pump

Power(W)

30.1KW(40.36hp)

Key attributes

Power Type

Diesel

Brand Name

ZHONGMEI

Max. vertical conveying distance

120 m(393.70ft)

Max. horizontal conveying distance

250m(820.21ft)

Productivity

15M³/H(529.72ft3/h)

Place of Origin

Other

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Key attributes

Productivity
15M³/H(529.72ft3/h)
Max. vertical conveying distance
120 m(393.70ft)
Max. horizontal conveying distance
250m(820.21ft)
Power Type
Diesel
Core Components
Motor, Gear, Pump, Other
Warranty
1 Year
UNIQUE SELLING POINT
Low fuel consumption
Machinery Test Report
Provided
Video outgoing-inspection
Provided
Brand Name
ZHONGMEI
Place of Origin
Shandong, China
Weight
1500 kg
Dimension(L*W*H)
3400*1100*1700mm(133.86*43.31*66.93in)
Product name
Concrete Conveying Pump
Keyword
Fine Stone Structure Pouring Pump
Maximum Pumping Concrete Pressure
10Mpa
Distribution Valve Form
S-pipe valve
Concrete Conveying Cylinder Bore*Stroke
140*650mm
Outlet Diameter
100mm
Oil Pressure Of Stirring System
8MPa
Rated Speed
1280r/min
Hydraulic Circuit Form
open circuit
Pumping Xiyong Oil Pressure
18MPa

Packaging and delivery

Selling Units
Single item
Single package size
100X100X100 cm
Single gross weight
59.000 kg

Lead time
