คุณลักษณะ
originalชื่อแบรนด์
MGSF1N03LT1Gหมายเลขรุ่น
Chinaสถานที่กำเนิด
N-Channel 30 V 1.6A (Ta) 420mW (Ta) Surface Mount SOT-23-3 (TO-236)ลักษณะ
MGSF1N03LT1GManufacturer Product Number
onsemiManufacturer
Description:MOSFET N-CH 30V 1.6A SOT23-3
Category:Discrete Semiconductor Products Transistors FETs, MOSFETs
Part Status:Active
FET Type:N-Channel
Technology:MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):30 V
Current - Continuous Drain (Id) @ 25°C:1.6A (Ta)
Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
Rds On (Max) @ Id, Vgs:100mOhm @ 1.2A, 10V
Vgs (Max):±20V
Input Capacitance (Ciss) (Max) @ Vds:140 pF @ 5 V
Power Dissipation (Max):420mW (Ta)
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Supplier Device Package:SOT-23-3 (TO-236)
Package / Case:TO-236-3, SC-59, SOT-23-3
Base Product Number:MGSF1
