Attributes
380 V, 220 VVoltage
3.05kwPower(W)
Cutting and blanking of extra-thick industrial profilesApplicable Material
Guangdong, ChinaPlace of Origin
Gear, Motor, Pneumatic Components, Electrical Components, Cutting BladeCore Components
350 kgWeight
Warranty:1 Year
Key Selling Points:High Safety Level
Machinery Test Report:Provided
Brand Name:ZLWM
Dimension(L*W*H):630x1065x1425(mm)
Input Power:380V 220V 50Hz
Working Air Pressure:0.5-0.8 MPa
Total Power:3.05 kw
Spindle Power:3kw
Blade Speed:3000 rpm
Blade Specification:500 * 30 * 4.5 * 120T
Cutting Angle:90°
Max Cutting Width:300 mm
Max Cutting Stroke:150 mm
Cutting Method:Upward cutting from bottom to top
Cutting Length Accuracy:±0.1 mm
Angle Accuracy:5-10
Cutting Feed Speed:0-5 m/min
Machine Dimensions (L*W*H):630 * 1065 * 1425 mm
Total Weight:Approx 350 kg
Power Requirement:1.5² 380V 50Hz
Operating Temperature (24h):5-40°C
Relative Humidity:30-75 percent
Vibration Intensity:<0.5 kg
Grounding Resistance:<10 ohm independent grounding not series grounding
