Hot Selling Hybrid Inverter 5kw 50kw EU Stock Solar Power System Home Storage High Voltage Three Phase for Deye IP65
Hot Selling Hybrid Inverter 5kw 50kw EU Stock Solar Power System Home Storage High Voltage Three Phase for Deye IP65No reviews yet
Attributes
Three PhaseOutput Type
99%Inverter Efficiency
Zhejiang, ChinaPlace of Origin
Deye HV Hybrid Inverter 5-25Kw Three PhaseModel Number
DeyeBrand Name
160-800Input Voltage
Output Voltage:220/380V,230/400V 0.85Un-1.1Un
Output Current:50A
Output Frequency:50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
Size:408*638*237(Excluding connectors and brackets)
Type:DC/AC Inverters
Weight:30.5kg-80kg
Application:Solar Power System Home
Installation Style:Wall Hanging
Warranty:5Years/10 Years
Certificate:VDE4105,IEC61727/62116,VDE0126
MPPT Efficiency:99% Efficiency
Operating Temperature Range:-40 ~ +60℃
Battery type:Lithium-ion
Noise (dB):≤ 55 dB(A)
Cooling:Intelligent Air cooling
Ingress Protection(IP) Rating:IP65
Charging Strategy for Li-ion Battery:Self-adaption to BMS
Peak Power (off-grid)(W):1.5 times of rated power,10s
Key attributes
Output Type
Three Phase
Inverter Efficiency
99%
Place of Origin
Zhejiang, China
Model Number
Deye HV Hybrid Inverter 5-25Kw Three Phase
Brand Name
Deye
Input Voltage
160-800
Output Voltage
220/380V,230/400V 0.85Un-1.1Un
Output Current
50A
Output Frequency
50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
Size
408*638*237(Excluding connectors and brackets)
Type
DC/AC Inverters
Weight
30.5kg-80kg
Application
Solar Power System Home
Installation Style
Wall Hanging
Warranty
5Years/10 Years
Certificate
VDE4105,IEC61727/62116,VDE0126
MPPT Efficiency
99% Efficiency
Operating Temperature Range
-40 ~ +60℃
Battery type
Lithium-ion
Noise (dB)
≤ 55 dB(A)
Cooling
Intelligent Air cooling
Ingress Protection(IP) Rating
IP65
Charging Strategy for Li-ion Battery
Self-adaption to BMS
Peak Power (off-grid)(W)
1.5 times of rated power,10s
Packaging and delivery
Selling Units
Single item
Lead time
Customization options
Customized logo (Min. order: 200 sets)
Customized packaging (Min. order: 200 sets)
Graphic customization (Min. order: 200 sets)
View details
Product descriptions from the supplier
Customizable
Minimum order quantity: 1 set
$1,285-4,950
Variations
Select nowApplication: Hybrid Solar System
Hybrid Solar System
Output Power: 10 kW
10 kW
8 kW
20 kW
12 kW
5 kW
6 kW
25kw
+4
Inverter Type
High voltage Three Phase hybrid inverter
Customization options
Customized logo (Min. order: 200 sets)
Customized packaging (Min. order: 200 sets)
Graphic customization (Min. order: 200 sets)
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
