Attributes
2.5Design Pressure (mpa)
3 yearswarranty
High vacuum insulated effectivenesskey selling points
Pressure Vesselcore components
Providedmachinery test report
Providedvideo outgoing-inspection
volume (m³):0.41
working temperature(℃):-196 - 20 ℃
place of origin:Guang Dong,China
brand name:Hua Nan
dimension(l*w*h):2100*820 *1060 mm
inner material:S30408
outer material:SUS 304
Model Number::DPW650-500-1.59/2.5/3.45
working pressure::1.59/2.5/3.45 Mpa
Application Medium::LOX, LAr, LN2, LCO2, LNG
Usage::Storing liquefied gas
Design::Horizontal/verical
Static evaporation rate(%/d)::1.7%/d
Appearance::Refined Polish silver colour
Insulated Layer:multiple-25 Layers
Certification:ISO14001:2015/GB24159-2009/KGS
