HT Original New Infineon IPW60R037CSFD TO-247-3 600V 54A N-Channel Power MOSFET

No reviews yet
$3.46
Minimum order quantity: 100 pieces
Specification

Key attributes

Manufacturer Part Number

IPW60R037CSFD

Type

MOSFET

Brand Name

Infineon

Package Type

Tube

Description

IPW60R037CSFD is an original Infineon CoolMOS CSFD series N-channel power MOSFET in a TO-247-3 package. Featuring 600V drain-source voltage, 54A continuous drain current, and low 31mΩ Rds(on), it is designed for high-efficiency switching and high-voltage power conversion.

Place of Origin

China

Shipping
Select shipping

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Delivery via

Expect your order to be delivered before scheduled dates or receive a 5% delay compensation

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Only orders placed and paid through Alibaba.com can enjoy free protection by

Payment & financing

4 interest-free payments with

Key attributes

Manufacturer Part Number
IPW60R037CSFD
Type
MOSFET
Brand Name
Infineon
Package Type
Tube
Description
IPW60R037CSFD is an original Infineon CoolMOS CSFD series N-channel power MOSFET in a TO-247-3 package. Featuring 600V drain-source voltage, 54A continuous drain current, and low 31mΩ Rds(on), it is designed for high-efficiency switching and high-voltage power conversion.
Place of Origin
China
Package / Case
TO-247-3
Operating Temperature
-55°C ~ +150°C
Series
CoolMOS CSFD Series
Mfg Date Code
Newest Batch
Application
High Voltage Switching
Supplier Type
Original Manufacturer
Media Available
Datasheet PDF
Power - Max
245W
FET Type
N-Channel
FET Feature
Standard
Drain to Source Voltage (Vdss)
600V
Current - Continuous Drain (Id) @ 25°C
54A
Rds On (Max) @ Id, Vgs
31mΩ @ 10V
Vgs(th) (Max) @ Id
4V
Gate Charge (Qg) (Max) @ Vgs
136nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds
5.623nF
Current Rating (Amps)
54A
Power - Output
245W
Voltage - Rated
600V
Drive Voltage (Max Rds On, Min Rds On)
10V
Vgs (Max)
±30V
Configuration
Single
Current - Drain (Idss) @ Vds (Vgs=0)
1uA @ 600V
Current Drain (Id) - Max
54A
Resistance - RDS(On)
31mΩ
Transistor Type
MOSFET
Mounting Type
Surface Mount

Packaging and delivery

Selling Units
Single item
Single package size
8X8X2 cm
Single gross weight
0.030 kg
