Attributes
Three PhaseOutput Type
98.7%Inverter Efficiency
Zhejiang, ChinaPlace of Origin
GW50K-SDT-C30Model Number
GoodweBrand Name
1100VInput Voltage
Output Voltage:220/380V,230/400V,240/415V
Output Current:75.7A
Output Frequency:50Hz/60Hz
Size:646*484*230 mm
Type:DC/AC Inverters
Weight:33kg
MPPT Operating Voltage Range (V):140 ~ 1000
Start-up Voltage (V):160
Nominal Input Voltage (V):600
Max. Input Current per MPPT (A):40
Max. Short Circuit Current per MPPT (A):52
Operatin Temperature Range (°C):-30 ~ +60
Cooling Method:Smart Fan Cooling
User Interface:LED, LCD (Optional), WiFi + LAN + Bluetooth
Communication:RS485, WIFI + LAN + Bluetooth
Ingress Protection Rating:IP66
