Attributes
220v/380vvoltage
Mitsubishicnc control system
Medium Dutymachining capacity
2number of axes
Singleno. of spindles
4, 6, 8tool post stations
max. length of workpiece (mm):1000/1500/2000/3000
key selling points:High-Accuracy
repeatability (x/y/z) (mm):±0.005
positioning accuracy (mm):±0.005
warranty:1 Year
type:Horizontal
machinery test report:Provided
video outgoing-inspection:Provided
max. weight of workpiece(kg):100
travel (x axis)(mm):400
travel (z axis)(mm):1100
place of origin:Jiangsu, China
width of bed (mm):210 mm
dimension(l*w*h):3500*1900*1900
brand name:Minnuo
model number:CK6165E
weight:4400
range of spindle speed:10 - 85 r.p.m
cutting torque:10
Product name:GSK System CNC Lathe Parts and Functional Processing Flange
CNC Controller:Siemens,FANUC,GSK,MITSUBISHI
CNC or Not:CNC Lathe Machine
Positioning Accuracy (mm):±0.005
Repeatability (X/Y/Z) (mm):±0.005
X axis rapid traverse:4m/min
Z axis rapid traverse:5m/min
X axis servo motor torque:10 N.m
Z axis servo motor torque:15/22/30N.m
Guide way type:Hard rail
