Full Color LED Waterproof Cabinet Video Wall OEM CMS Welcome Display Shopping Mall Exhibition Hall SDK P2.976 Pixel IP65 Rating
No reviews yet
Attributes
168x168, 168x336resolution
16:9, Otheraspect ratio
Outdoorapplication
5000~5500 Nitsbrightness
IP54, IP65ip rating
3 mmPixels
Screen Type:Led
warranty:2 Years
place of origin:Guangdong, China
Remote Device Management:No
specification:LED cabinet
use:Exhibition Hall, Shopping Mall, Welcome Display, LED video wall
model number:Aor 2.9 Max
brand name:Aistartech
color:Full Color
Color Depth:14~16Bit
Content Management System:Yes
Contrast Ratio:10000:1
Control Method:Computer
Dimensions:500*500mm, 500×1000 mm
Display Function:Animation
function:SDK
installation type:Hanging Stacking
lifespan (hours):10000
Material:Die Casting Aluminum
media available:Other
Mounting type:Hanging, Stacking
Operating Temperature:-40℃-80℃
Operation System:Windows
panel brand:Aistartech
Pixel Density:112896
Pixel Pitch:P2.976
response time:≤5ms
supplier type:Original Manufacturer, ODM, OEM
Touch Screen:No Touch
Usage environment:Indoor
view angle（h/v）:140°/ 120°
Voltage:100-110V, 200-240V
Pixel Structure (SMD:1415
Module resolution (W*H:72*48
Module weight (kg):2
Box module composition (W*H):2*3
Box resolution (W*H:168x168/168x336
Box size (mm:500*500/1000*500
Box area (㎡):0.25/0.5
Regular weight (kg per box):24.5
Pixel density (points /㎡):112896
IP rating:IP65/IP54
Gray scale level (bit:14~16
Color temperature (K:6500-9000
Uniformity of brightness:≥97%
Chromaticity uniformity:±0.003Cx, Cy
Maximum power consumption (W/㎡:750
Average power consumption (W/㎡:248
Power supply requirements:AC100~240V
Frame change frequency (Hz:50&60
Refresh rate (Hz:3840
LED lifespan (hrs):100,000
Key attributes
resolution
168x168, 168x336
aspect ratio
16:9, Other
application
Outdoor
brightness
5000~5500 Nits
ip rating
IP54, IP65
Pixels
3 mm
Operating Temperature
-40℃-80℃
warranty
2 Years
Screen Type
Led
function
SDK
Display Function
Animation
Content Management System
Yes
specification
LED cabinet
Remote Device Management
No
supplier type
Original Manufacturer, ODM, OEM
media available
Other
use
Exhibition Hall, Shopping Mall, Welcome Display, LED video wall
Operation System
Windows
Pixel Density
112896
response time
≤5ms
place of origin
Guangdong, China
model number
Aor 2.9 Max
brand name
Aistartech
color
Full Color
Color Depth
14~16Bit
Contrast Ratio
10000:1
Control Method
Computer
Dimensions
500*500mm, 500×1000 mm
installation type
Hanging Stacking
lifespan (hours)
10000
Material
Die Casting Aluminum
Mounting type
Hanging, Stacking
panel brand
Aistartech
Pixel Pitch
P2.976
Touch Screen
No Touch
Usage environment
Indoor
view angle（h/v）
140°/ 120°
Voltage
100-110V, 200-240V
Pixel Structure (SMD
1415
Module resolution (W*H
72*48
Module weight (kg)
2
Box module composition (W*H)
2*3
Box resolution (W*H
168x168/168x336
Box size (mm
500*500/1000*500
Box area (㎡)
0.25/0.5
Regular weight (kg per box)
24.5
Pixel density (points /㎡)
112896
IP rating
IP65/IP54
Gray scale level (bit
14~16
Color temperature (K
6500-9000
Uniformity of brightness
≥97%
Chromaticity uniformity
±0.003Cx, Cy
Maximum power consumption (W/㎡
750
Average power consumption (W/㎡
248
Power supply requirements
AC100~240V
Frame change frequency (Hz
50&60
Refresh rate (Hz
3840
LED lifespan (hrs)
100,000
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
1 - 399 pieces
$159
400 - 1599 pieces
$153
>= 1600 pieces
$145
Variations
Select now屏幕尺寸
500*500*72
1000*500
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
