Frameless Motor OD38mm Torque 0.2NM Height 22mm Bldc Direct Drive Torque Motor for Medical Surgery Robot Arm and Joint Actuator
Store rating:4.6
(15 reviews)
Attributes
BrushlessCommutation
63WRated Power
3 000 RPMSpeed Rpm
4000-6000 RPMSpeed(RPM)
otherIP Rating
IE 4Efficiency
Continuous Current(A):custom
Place of Origin:China
Frame:No
Motor Mounting Type:Foot Mount
Model Number:U3822
Brand Name:other
Construction:Permanent Magnet
Protect Feature:Totally Enclosed
Torque:0.2NM
Type:Brushless Motor
Usage:Home Appliance, Cosmetic Instrument, Smart Home, Medical machinery
Warranty:Other
OD(mm):38
Height(mm):22.3
Voltage(V):48
Rated Output (W):63
Rated torque (Nm):0.2
Instant Max Torque (Nm):0.6
Rated Current (Arms):3.5
Instant Max Current*1 (Arms):10.5
Rated Speed (rpm):3000
Max Speed*1 (Rpm):6000
Key attributes
Commutation
Brushless
Rated Power
63W
Speed Rpm
3 000 RPM
Speed(RPM)
4000-6000 RPM
IP Rating
other
Efficiency
IE 4
Type
Brushless Motor
Construction
Permanent Magnet
Frame
No
Motor Mounting Type
Foot Mount
Protect Feature
Totally Enclosed
Usage
Home Appliance, Cosmetic Instrument, Smart Home, Medical machinery
Warranty
Other
Continuous Current(A)
custom
Model Number
U3822
Torque
0.2NM
Brand Name
other
Place of Origin
China
OD(mm)
38
Height(mm)
22.3
Voltage(V)
48
Rated Output (W)
63
Rated torque (Nm)
0.2
Instant Max Torque (Nm)
0.6
Rated Current (Arms)
3.5
Instant Max Current*1 (Arms)
10.5
Rated Speed (rpm)
3000
Max Speed*1 (Rpm)
6000
Packaging and delivery
Selling Units
Single item
Package size per batch
12X12X12 cm
Gross weight per batch
30.000 kg
Lead time
Product descriptions from the supplier
2 - 99 pieces
$60
100 - 299 pieces
$50
300 - 999,999 pieces
$25
>= 1,000,000 pieces
$10
Variations
Select nowRated voltage: /
/
Output Power: 63W
63W
Speed of Revolution
3000
