Frameless Brushless Permanent Magnet Robot Arm Motor OD38mm Height22.6mm Torque0.35NM Direct Drive Robot Joint Module
Store rating:4.4
(17 reviews)
Attributes
BrushlessCommutation
62.9WRated Power
3000Speed Rpm
3000Speed(RPM)
otherIP Rating
IE 4Efficiency
Continuous Current(A):custom
Place of Origin:China
Frame:NO
Motor Mounting Type:Glue type
Model Number:U3822
Brand Name:other
Construction:Permanent Magnet
Protect Feature:Totally Enclosed
Torque:0.2NM
Type:Brushless Motor
Usage:Robot
Warranty:Other
OD(mm):38
Height(mm):22.6
Voltage(VDC):48
Rated Output*1 (W):62.9
Rated torque*1 (Nm):0.2
Instant Max Torque*1 (Nm):0.6
Rated Current*1 (Arms):3.5
Instant Max Current*1 (Arms):10.5
Rated Speed*1 (Rpm):3000
Max Speed*1 (Rpm):6000
Key attributes
Commutation
Brushless
Rated Power
62.9W
Speed Rpm
3000
Speed(RPM)
3000
IP Rating
other
Efficiency
IE 4
Type
Brushless Motor
Construction
Permanent Magnet
Frame
NO
Motor Mounting Type
Glue type
Protect Feature
Totally Enclosed
Usage
Robot
Warranty
Other
Continuous Current(A)
custom
Model Number
U3822
Torque
0.2NM
Place of Origin
China
Brand Name
other
OD(mm)
38
Height(mm)
22.6
Voltage(VDC)
48
Rated Output*1 (W)
62.9
Rated torque*1 (Nm)
0.2
Instant Max Torque*1 (Nm)
0.6
Rated Current*1 (Arms)
3.5
Instant Max Current*1 (Arms)
10.5
Rated Speed*1 (Rpm)
3000
Max Speed*1 (Rpm)
6000
Packaging and delivery
Selling Units
Single item
Single package size
12X12X12 cm
Single gross weight
40.000 kg
Lead time
Product descriptions from the supplier
2 - 299 pieces
$88
>= 300 pieces
$38
Variations
Select nowRated voltage: /
/
Output Power: 62.9 W
62.9 W
Speed of Revolution
3000 RPM
