Attributes
Ip56, IP66, otherIngress Protection
Differential Pressure Level Transmitterstype
United Statesplace of origin
3051Lmodel number
Emerson/Rosemountbrand name
OEMcustomized support
material:316/316L
warranty:1 Year
Max. Operating Pressure:Up to 300 psi (20,68 bar)
Process Temperature Range:Maximum 401°F (205°C), Minimum -157°F (-105°C)
Communication Protocol:4-20 MA HART
Seal System Type:Direct Mount, Tuned-System
Transmitter Connection:Welded-Repairable
Process Connection:Flanged: ANSI/ASME, EN/DIN, JIS
Process Wetted Material:316L SST, Alloy C-276, Tantalum
Power Module Life:Up to 10-year life, field replaceable (order separately)
Wireless Range:Internal antenna (225 m)
Wireless Update Rate:1 sec. to 60 min., user selectable
