Domestically Produced Small-Sized FPGA Development Board Hole Technology Model PH1P35MDG324 DDR2 512Mb ERAM 2160Kbits High-Speed
No reviews yet
Attributes
Not ApplicableMain Purpose
NoEmbedded
Not ApplicableOutputs and Type
/Operating System
Evaluation PlatformBoard Type
I2C, uart, SPI, USBCommunication Interface
Type:Development Board
Core Processor:PH1P35MDG324
Interface:/
Description:Anlogic PH1P35 Development Board
Model Number:MLKPAI-F02-PH1P35MDG324
Place of Origin:Jiangsu, China
Brand Name:MILIANKE
Series:Anlogic PH1P series
Mfg. Date Code:/
Package:MDG324
Function:high-speed communication, video transmission
Utilized IC / Part:/
Number of A/D Converters:/
Number of Bits:/
Sampling Rate (Per Second):/
Data Interface:/
Input Range:/
Amplifier Type:/
Output Type:/
Max Output Power x Channels @ Load:/
Voltage - Supply:5V/3A
Power - Output:/
Voltage - Output:/
Current - Output:/
Voltage - Input:/
Frequency - Switching:/
Platform:/
Mounting Type:/, PCB
Current - Output / Channel:/
Features:/
Channels per IC:/
Regulator Type:/
-3db Bandwidth:/
Current - Supply (Main IC):/
Voltage - Supply, Single/Dual (±):/
Sensor Type:/
Sensitivity:/
Module/Board Type:/
Maximum Number Of IC's:/
Maximum Time:/
Sensing Range:/
Model:PH1P35MDG324
LUT4s:38189
DFFs(Flip-Flops):42432
DSP:40
PLL:6
Dis-RAM:507
ERAMa-20K:108
ERAMa-Total(Kbits):2160
DDR2:512Mb DDR2
FLASH:128Mbit FLASH
Key attributes
Main Purpose
Not Applicable
Embedded
No
Outputs and Type
Not Applicable
Operating System
/
Board Type
Evaluation Platform
Communication Interface
I2C, uart, SPI, USB
Type
Development Board
Core Processor
PH1P35MDG324
Interface
/
Description
Anlogic PH1P35 Development Board
Model Number
MLKPAI-F02-PH1P35MDG324
Place of Origin
Jiangsu, China
Brand Name
MILIANKE
Series
Anlogic PH1P series
Mfg. Date Code
/
Package
MDG324
Function
high-speed communication, video transmission
Utilized IC / Part
/
Number of A/D Converters
/
Number of Bits
/
Sampling Rate (Per Second)
/
Data Interface
/
Input Range
/
Amplifier Type
/
Output Type
/
Max Output Power x Channels @ Load
/
Voltage - Supply
5V/3A
Power - Output
/
Voltage - Output
/
Current - Output
/
Voltage - Input
/
Frequency - Switching
/
Platform
/
Mounting Type
/, PCB
Current - Output / Channel
/
Features
/
Channels per IC
/
Regulator Type
/
-3db Bandwidth
/
Current - Supply (Main IC)
/
Voltage - Supply, Single/Dual (±)
/
Sensor Type
/
Sensitivity
/
Module/Board Type
/
Maximum Number Of IC's
/
Maximum Time
/
Sensing Range
/
Model
PH1P35MDG324
LUT4s
38189
DFFs(Flip-Flops)
42432
DSP
40
PLL
6
Dis-RAM
507
ERAMa-20K
108
ERAMa-Total(Kbits)
2160
DDR2
512Mb DDR2
FLASH
128Mbit FLASH
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
Minimum order quantity: 2 pieces
$7680
Variations
Select nowSpecification
MLKPAI-F02-FC02-PH1P35MDG324
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
