Deye SUN-3/4/5/6/7/8/9/10/12/15K-G06P3-EU-BM2 On Grid Inverter 3kW to 15kW Power Range Compact Design
No reviews yet
Attributes
Three PhaseOutput Type
98.5%Inverter Efficiency
Zhejiang, ChinaPlace of Origin
SUN-3/4/5/6/7/8/9/10/12/15K-G06P3-EU-BM2Model Number
DeyeBrand Name
1100VInput Voltage
Output Voltage:220/380V, 230/400V
Output Current:4.6/4.4A-22.8/21.8A
Output Frequency:50Hz/60Hz
Size:283*525*178 mm
Type:DC/AC Inverters
Weight:11.5KG
Max. PV Input Voltage (V):1100
Start-up Voltage(V):140
MPPT voltage range(V):120-1000
Rated PV Input voltage(V):600
MPPT Efficiency:>99%
Communication Interface:RS485/RS232
Monitor Mode:GPRS/WIFI/Bluetooth/4G/LAN(optional)
Ingress Protection(IP) Rating:IP 65
Inverter Topology:Non-Isolated
Warranty [year]:5 Years
Key attributes
Output Type
Three Phase
Inverter Efficiency
98.5%
Place of Origin
Zhejiang, China
Model Number
SUN-3/4/5/6/7/8/9/10/12/15K-G06P3-EU-BM2
Brand Name
Deye
Input Voltage
1100V
Output Voltage
220/380V, 230/400V
Output Current
4.6/4.4A-22.8/21.8A
Output Frequency
50Hz/60Hz
Size
283*525*178 mm(11.14*20.67*7.01in)
Type
DC/AC Inverters
Weight
11.5KG(25.35lb)
Max. PV Input Voltage (V)
1100
Start-up Voltage(V)
140
MPPT voltage range(V)
120-1000
Rated PV Input voltage(V)
600
MPPT Efficiency
>99%
Communication Interface
RS485/RS232
Monitor Mode
GPRS/WIFI/Bluetooth/4G/LAN(optional)
Ingress Protection(IP) Rating
IP 65
Inverter Topology
Non-Isolated
Warranty [year]
5 Years
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
1 - 49 sets
$609
>= 50 sets
$590
Variations
Select nowApplication: On-Grid Solar System
On-Grid Solar System
Output Power: 10 kW(13.41hp)
10 kW(13.41hp)
8 kW(10.73hp)
7 kW(9.39hp)
12 kW(16.09hp)
3 kW(4.02hp)
4 kW(5.36hp)
5 kW(6.71hp)
+3
Inverter Type
String Inverter
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
