Deye SUN-3/4/5/6/7/8/9/10/12/15K-G06P3-EU-AM2-P1 15kW Max Power On Grid Inverter For Commercial Solar Systems
No reviews yet
Attributes
Three PhaseOutput Type
DC/AC InvertersType
DeyeBrand Name
98.5%Inverter Efficiency
Zhejiang, ChinaPlace of Origin
SUN-3/4/5/6/7/8/9/10/12/15K-G06P3-EU-AM2-P1Model Number
Input Voltage:1100V
Output Voltage:220/380V, 230/400V
Output Current:4.6/4.4A-22.8/21.8A
Output Frequency:50Hz/60Hz
Size:283*463*178 mm
Weight:11KG
Max. PV Input Voltage (V):1100
Start-up Voltage (V):140
MPPT Voltage Range (V):120-1000
Rated PV Input Voltage (V):600
MPPT Efficiency:>99%
Communication Interface:RS485/RS232
Monitor Mode:GPRS/WIFI/Bluetooth/4G/LAN(optional)
Ingress Protection(IP) Rating:IP 65
Inverter Topology:Non-Isolated
Warranty [year]:5 Years
Key attributes
Output Type
Three Phase
Type
DC/AC Inverters
Brand Name
Deye
Inverter Efficiency
98.5%
Place of Origin
Zhejiang, China
Model Number
SUN-3/4/5/6/7/8/9/10/12/15K-G06P3-EU-AM2-P1
Input Voltage
1100V
Output Voltage
220/380V, 230/400V
Output Current
4.6/4.4A-22.8/21.8A
Output Frequency
50Hz/60Hz
Size
283*463*178 mm
Weight
11KG
Max. PV Input Voltage (V)
1100
Start-up Voltage (V)
140
MPPT Voltage Range (V)
120-1000
Rated PV Input Voltage (V)
600
MPPT Efficiency
>99%
Communication Interface
RS485/RS232
Monitor Mode
GPRS/WIFI/Bluetooth/4G/LAN(optional)
Ingress Protection(IP) Rating
IP 65
Inverter Topology
Non-Isolated
Warranty [year]
5 Years
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
1 - 49 sets
$465
>= 50 sets
$380
Variations
Select nowApplication: On-Grid Solar System
On-Grid Solar System
Output Power: 3kw(4.02hp)
3kw(4.02hp)
9kw(12.07hp)
10kw(13.41hp)
4kw(5.36hp)
5kw(6.71hp)
6kw(8.05hp)
7kw(9.39hp)
+3
Inverter Type
String Inverter
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
