Deye SUN-23/25/30K-G04-LV 30kW Max Power On Grid Inverter For Home Solar Systems Low Voltage Design Safe
No reviews yet
Attributes
Three PhaseOutput Type
DC/AC InvertersType
DeyeBrand Name
98.7%Inverter Efficiency
Zhejiang, ChinaPlace of Origin
SUN-23/25/30K-G04-LVModel Number
Input Voltage:400V
Output Voltage:127V/220V, 133V/230V
Output Current:60.4/57.7A-78.8/75.2A
Output Frequency:50Hz/60Hz
Size:434*570*243 mm
Weight:37.1KG
Max. PV Input Voltage(V):800
Start-up Voltage(V):250
MPPT voltage range(V):200-700
Rated PV Input voltage(V):350
MPPT Efficiency:>99%
Communication Interface:RS485/RS232
Monitor Mode:GPRS/WIFI/Bluetooth/4G/LAN(optional)
Ingress Protection(IP) Rating:IP 65
Inverter Topology:Non-Isolated
Warranty [year]:5 Years
Key attributes
Output Type
Three Phase
Type
DC/AC Inverters
Brand Name
Deye
Inverter Efficiency
98.7%
Place of Origin
Zhejiang, China
Model Number
SUN-23/25/30K-G04-LV
Input Voltage
400V
Output Voltage
127V/220V, 133V/230V
Output Current
60.4/57.7A-78.8/75.2A
Output Frequency
50Hz/60Hz
Size
434*570*243 mm
Weight
37.1KG
Max. PV Input Voltage(V)
800
Start-up Voltage(V)
250
MPPT voltage range(V)
200-700
Rated PV Input voltage(V)
350
MPPT Efficiency
>99%
Communication Interface
RS485/RS232
Monitor Mode
GPRS/WIFI/Bluetooth/4G/LAN(optional)
Ingress Protection(IP) Rating
IP 65
Inverter Topology
Non-Isolated
Warranty [year]
5 Years
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
1 - 49 sets
$1,210
>= 50 sets
$1,030
Variations
Select nowApplication: On-Grid Solar System
On-Grid Solar System
Output Power: 23kw
23kw
25kw
30kw
Inverter Type
String Inverter
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
