Deye Hybrid Solar Inverter 14KW 3 Phase SUN-14K-SG05LP3-EU-SM2 48V on off Grid Solar Hybrid Inverter for Home
No reviews yet
Attributes
Three PhaseOutput Type
DC/AC InvertersType
DeyeBrand Name
97.60%Inverter Efficiency
Zhejiang, ChinaPlace of Origin
SUN-14K-SG05LP3-EU-SM2Model Number
Input Voltage:160V
Output Voltage:220/380V, 230/400V
Output Current:70A
Output Frequency:50Hz/ 60Hz
Size:456*750*268.5mm
Weight:50.6kg
Battery Type:Lead-acid or Lithium-ion
Battery Voltage Range:40-60
Charging Strategy for Li-ion Battery:Self-adaption to BMS
Max. DC Input Voltage:800V
MPPT Voltage Range:160-650V
Rated DC Input Voltage:550V
Grid Connection Form:3L+N+PE
MPPT Efficiency:>99%
Communication Interface:WIFI, RS485, CAN
Ingress Protection(IP) Rating:IP 65
Product spotlightsMPPT Efficiency: The high MPPT efficiency of over 99% ensures maximum energy conversion, optimizing the performance of the solar system.
Ingress Protection Rating: With an IP65 rating, the inverter is well-protected against dust and water, making it suitable for both indoor and outdoor installations.
Key attributes
Output Type
Three Phase
Type
DC/AC Inverters
Brand Name
Deye
Input Voltage
160V
Inverter Efficiency
97.60%
Model Number
SUN-14K-SG05LP3-EU-SM2
Output Current
70A
Output Frequency
50Hz/ 60Hz
Output Voltage
220/380V, 230/400V
Place of Origin
Zhejiang, China
Size
456*750*268.5mm(17.95*29.53*10.57in)
Weight
50.6kg(111.55lb)
Battery Type
Lead-acid or Lithium-ion
Battery Voltage Range
40-60
Charging Strategy for Li-ion Battery
Self-adaption to BMS
Max. DC Input Voltage
800V
MPPT Voltage Range
160-650V
Rated DC Input Voltage
550V
Grid Connection Form
3L+N+PE
MPPT Efficiency
>99%
Communication Interface
WIFI, RS485, CAN
Ingress Protection(IP) Rating
IP 65
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
Minimum order quantity: 1 set
$1,796-2,477
Variations
Select nowApplication: Hybrid Solar System
Hybrid Solar System
Output Power: 14kw(18.77hp)
14kw(18.77hp)
15kw(20.12hp)
16kw(21.46hp)
18kw(24.14hp)
20kw(26.82hp)
Inverter Type
String Inverter
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
