Sanitary SUS316L Micro Gear Pump Food Grade Magnetic Dosing Pump 7.3L/min High Precision for Liquid Filling & Metering

No reviews yet4 sold
$318.46
1-99 pieces
$254.77
100-499 pieces
$212.31
≥500 pieces
Select now

Flow Rate

7.3L/min(water as medium)

maximum head

other

type

gear pump

+ 1 more variants

Customization options
motor (Min. order: 1 piece)

Key attributes

application

Automotive Industry

pressure

0.35MPa

customized support

OEM, ODM, OBM

place of origin

Guangdong, China

power source

Electric

warranty

1 Year

At a glance

  • SUS316L Pump Body: Constructed from SUS316L stainless steel, this pump body ensures high resistance to corrosion and durability, making it suitable for use with a wide range of chemicals.

  • 7.3L/min Max Flow Rate: With a maximum flow rate of 7.3 liters per minute, this pump can efficiently handle high-volume fluid transfer, ideal for filling and metering applications.

  • 0.35MPa Max Pressure: Capable of operating at a maximum pressure of 0.35 MPa, this pump is well-suited for applications requiring precise and reliable fluid control under moderate pressure conditions.

  • -40 to 105°C Temperature Range: The pump's ability to operate within a temperature range of -40 to 105 degrees Celsius makes it versatile for use in both cold and hot environments, ensuring consistent performance across various conditions.

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Only orders placed and paid through Alibaba.com can enjoy free protection by

Finance Service

4 interest-free payments with

Key attributes

application
Automotive Industry
pressure
0.35MPa
customized support
OEM, ODM, OBM
place of origin
Guangdong, China
power source
Electric
warranty
1 Year
model number
GQA175FSLD01
brand name
DOCOD
Applicable temperature
-40 to 105 degrees Celsius
Chemical Compatibility
Alcohol, Diesel, oils, Water
Max Flow Rate
7.3L/min
Max Pressure
0.35MPa
motor
Servo Motor, Stepper Motor, Brushless DC Motor
Sealing Material
Ceramic
structure
Gear Pump
Material
Stainless Steel
Nominal Displacement
1.75ml/rev
Max. Flow Rate
7.3L/min(water as medium)
Max. Pressure
0.35MPa
Viscosity Range
0.5-1500CP
Operating Speeds
500-4200rpm
Rated Voltage
24VDC
Rated Power
70W
Gear Material
PEEK
Pump Body Material
SUS316L
Static Seal
PTFE (gaskets), EPDM (O-rings)
thread specifications
Standard configuration G1/8-28(customizable)
Compatible Drive
Brushless DC Motor, Stepper Motor, Servo Motor
Temperature resistance
-40 to 105 degrees Celsius
