BFSS5 SS316L Stainless Steel NPT/BSPT/SW Universal Connector Swivel Rotary Horizontal Ball Float and Thermostatic Steam Trap
See store reviews
Attributes
DN25port size
Ball Float and Thermostaticstructure
Steam Traptype
OEMcustomized support
Taiwan, Chinaplace of origin
Generalapplication
power:Hydraulic
model number:BFSS5
brand name:BOWLING
media:Gas
temperature of media:High Temperature
warranty:1 year
Body:ASTM A351 CF8. CF8M SS304 SS316 SS316L
Gasket:Graphite
Seat & Valve:Chrome Steel Hardened SS440
Mechanism:SUS304
Connection 1:NPT (ANSI BI.20.1), BSPT (BS21.0), BSPF SW
Connection 2:Flanged End JIS10K. JIS25 ANSI150. ANSI300. PN16. PN25
Max. Operating pressure:32 BAR. 32 KGS
Operating temperature:320 DEG.C
Flow Direction:Horizontal Direction
Optional:Thermostatic Air Valve
Key attributes
port size
DN25
structure
Ball Float and Thermostatic
type
Steam Trap
customized support
OEM
place of origin
Taiwan, China
application
General
power
Hydraulic
model number
BFSS5
brand name
BOWLING
media
Gas
temperature of media
High Temperature
warranty
1 year
Body
ASTM A351 CF8. CF8M SS304 SS316 SS316L
Gasket
Graphite
Seat & Valve
Chrome Steel Hardened SS440
Mechanism
SUS304
Connection 1
NPT (ANSI BI.20.1), BSPT (BS21.0), BSPF SW
Connection 2
Flanged End JIS10K. JIS25 ANSI150. ANSI300. PN16. PN25
Max. Operating pressure
32 BAR. 32 KGS
Operating temperature
320 DEG.C
Flow Direction
Horizontal Direction
Optional
Thermostatic Air Valve
Packaging and delivery
Selling Units
Single item
Single package size
20X20X20 cm
Single gross weight
8.000 kg
Lead time
Customization options
Logo customized (Min. order: 10 sets)
Packing customized (Min. order: 1,000 sets)
Graphic customized (Min. order: 1,000 sets)
View details
Product descriptions from the supplier
FREE shipping capped at $20
100 - 199 sets
$700
200 - 499 sets
$630
500 - 999 sets
$570
>= 1,000 sets
$520
Sample price: $750
Variations
Select nowmaterial: Stainless Steel
Stainless Steel
pressure: Medium Pressure
Medium Pressure
size
1 in
