Attributes
WalsinBrand Name
SF10F_QModel Number
Taiwan, ChinaPlace of Origin
- 55~ +150'COperating Temperature
±1% ,±0.5% , ±0.25% , ±0.1% , ±0.05%Tolerance
1210(3225)Size
Resistance:25Ω ~400KΩ
Rated Power:1/4W
Terminal strength:1 kg for 60 s
Vibration:5 g's for 20 min , 12 cycles each of 3 orientations
Mechanical Shock:d 213 1/2 Sine Pulse / 1500g Peak / Velocity 15.4ft/sec
Moisture Resistance:65±2°C, 80~100% RH, 10 cycles, 24 hours/ cycle
High Temperature Exposure:1000 hrs @ 125℃, un-powered
Operational Life:1,000 hours at 85±5 °C
