24V Brushless DC Motor Kit Electric Scooter Forklift Permanent Magnet 3000 RPM 125W 7A 0.4Nm Torque Series Wound 71mm Frame

No reviews yet

Attributes

BrushlessCommutation
125WRated Power
3 000 RPMSpeed Rpm
3000 RPMSpeed(RPM)
IE 2Efficiency
Brushless MotorType
Construction:Series Wound
Frame:71mm
Motor Mounting Type:Panel Mount
Protect Feature:Other
Usage:3D Printer
Warranty:1 Year
Continuous Current(A):7A
Model Number:57BLY12530
Torque:0.4N.m
Place of Origin:Jiangsu, China
Rated Power:125W
Phase Current:24VDC
Rated Torque:0.4N.m
Rated Current:7A
Rated Speed:3000RPM
Peak Current:21A
Peak Torque:1.2 N.m
Nuber of Polse:4
Torque Constant:4.2 V/Krpm
Body Length:71mm
Step Accuracy:±5%
Resistance Accuracy:±10%
Inductance Accuracy:±20%
Temperature Rise:Max.80℃
Ambient Temperature:-20℃ to +50℃
Insulation Resistance:Min.100MΩ, 500V DC
Withstand Voltage:500V AC, 1 minute

Key attributes

Commutation
Brushless
Rated Power
125W
Speed Rpm
3 000 RPM
Speed(RPM)
3000 RPM
Efficiency
IE 2
Type
Brushless Motor
Construction
Series Wound
Frame
71mm(2.80in)
Motor Mounting Type
Panel Mount
Protect Feature
Other
Usage
3D Printer
Warranty
1 Year
Continuous Current(A)
7A
Model Number
57BLY12530
Torque
0.4N.m(0.30lb.ft)
Place of Origin
Jiangsu, China
Rated Power
125W
Phase Current
24VDC
Rated Torque
0.4N.m
Rated Current
7A
Rated Speed
3000RPM
Peak Current
21A
Peak Torque
1.2 N.m
Nuber of Polse
4
Torque Constant
4.2 V/Krpm
Body Length
71mm
Step Accuracy
±5%
Resistance Accuracy
±10%
Inductance Accuracy
±20%
Temperature Rise
Max.80℃
Ambient Temperature
-20℃ to +50℃
Insulation Resistance
Min.100MΩ, 500V DC
Withstand Voltage
500V AC, 1 minute

Packaging and delivery

Selling Units
Single item
Single package size
23X13X16.5 cm
Single gross weight
2.600 kg

Lead time

Product descriptions from the supplier

1 - 9 pieces
$3399
10 - 99 pieces
$3099
>= 100 pieces
$2799

Variations

Select now

Rated voltage: Dc 24V

Dc 24V

Output Power: 125W

125W

Speed of Revolution

3000RPM
